5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle

5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle
5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle 5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle 5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle

Large Image :  5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle

Product Details:
Place of Origin: ningbo china
Brand Name: Linkai
Certification: iso ce
Model Number: sjs
Payment & Shipping Terms:
Minimum Order Quantity: 10pcs
Price: get the latest
Packaging Details: wooden case
Delivery Time: 5-8work days
Payment Terms: T/T, L/C, Western Union
Supply Ability: 1000pcs/day
Detailed Product Description
Name: Double Hook Steel Turnbuckle Model: Sjs-0.5
Rated Load: 5kn Max Center Distance: 800mm
Adjustable Distance: 250mm Weight: 2.5kg
High Light:

electrical wire pulling tools

,

stringing pulling tools

5KN Rated Load Double Hook Wire Tightening Tool Steel Wire Rope Turnbuckle



Our steel double hook turnbuckle plays a role in tightening the steel wire rope, stranded steel wire, and some others. This product from 14113 to 14116 can be also provided with the ring structure, which must be clearly indicated in the contract.



Quick Information:

1. name: dual hook steel turnbuckle

2. model:SJS-05

3. Type, conductor wire rope tightening tools, steel wire rope turnbuckle

4. material:steel

5.Brand: ningbo donghuan

6.Max center distance: 800mm

7.Adjustable distance:300mm



Detailed Data

Item number Model Rated load (kN) Maximum center distance Adjustable distance (mm) Weight (kg) Remark
14111 SJS-0.5 5 800 300 2.5 Steel
14112 SJS-1 10 860 250 3.5
14113 SJS-2 20 1050 340 4
14114 SJS-3 30 1350 470 6
14115 SJS-5 50 1440 510 8
14116 SJS-8 80 1670 560 8.5
14117 SJS-10 100 1740 600 10
14121 SJSL-1 10 768 290 2 Aluminum Alloy
14122 SJSL-2 20 936 350 2.5
14123 SJSL-3 30 1296 530 4.5
14124 SJSL-5 50 1500 630 6



5KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle 05KN Double Hook Electrical Cable Pulling Tools Steel Wire Rope Turnbuckle 1
